Multi-ply fabric conveyor belt:
Multi-ly fabric conveyor belt uses fabric as carcass,and it can be improved for more performances by
changing the ingredient of the cover rubber.
| Fabric Type |
Ply Strength (N/mm) |
Ply Thickness (mm) |
Cover Thickness (mm) | No.s of Ply |
Width Range (mm) |
|
| Top | Bottom | |||||
| EP/NN100 | 100 | 0.75 |
3 4.5 6 |
1.5 3 6 |
1~12 | 400-2200 |
| EP/NN 125 | 125 | 0.75 | ||||
| EP/NN 150 | 150 | 0.85 | ||||
| EP/NN 200 | 200 | 1.00 | ||||
| EP/NN 250 | 250 | 1.20 | ||||
| EP/NN 300 | 300 | 1.35 | ||||
| EP/NN 400 | 400 | 1.65 | ||||
| CC56 | 56 | 1.10 | ||||
| CC70 | 70 |
1.00 |
||||
The advantage:
Good performance of fatigue resistance
· Impact resistant
· Low elongation
· Good flexibility & good troughability
Aplication of Multi-ply fabric conveyor belt:
Multi-ply fabric conveyor blet is widely used in surface mining,harbor,chemichal, metallurgy industry
and so on,based on it's low cost and mature craft.
